GM Automatic Overdrive Transmission Builder’s Guide

GM AUTOMATIC OVERDRIVE TRANSMISSION

Builder's & Swapper's Guide

By Cliff Ruggles
Featuring Special Swapping Section by Ro McGonegal

From SA Design "PERFORMANCE HOW-TO" Series

Covers 700-R4, 4L60 and 4L60E Transmissions
Model I.D., History and Evolution Guide
Factory and Aftermarket Upgrades
Parts Interchange Advice

There's an important component standing between your engine and your drive wheels: the transmission. Inside that metal case is a bewildering array of gears, bearings, seals and more. The automatic transmission is a miracle of modern engineering but it can also be a source of trouble. If your transmission breaks down you're not going anywhere, and if it's just not working properly, your car will never realize its performance potential.

In this book, expert mechanic and drag racer Cliff Ruggles demystifies the popular GM 700-R4 and 4L60 automatic transmissions. Keeping the enthusiast in mind, Ruggles explains the history of these transmissions, presents critical identification guidelines and leads the reader through the complete disassembly, repair and upgrade, and assembly processes. Learn how to test your transmission to ensure its proper operation before installing if in the car.

This book includes information about high-performance modifications, both from the factory and the aftermarket. These include internal parts and external components such as shift kits and torque converters that will help you make your transmission perform at its best. It also covers common installation issues such as mounting, shifters and linkages, wiring harnesses and more and includes a special section by Ro McGonegal on swapping these transmissions into earlier performance and musclecar chassis.

Published by SA Design - # SA140

Softcover - 126 Pages
